Cisco Industrial Ethernet 4000 Series

16 495 kr Ekskl. moms 512 kr. pr. måned (Leasing 36 måneder)
  • Lagerstatus: Bestillingsvare. Ukendt leveringstid.
  • Forsendelse fra: 69 kr
  • Varenummer
  • 5010926238
  • Prod. varenr.
  • IE-4000-16T4G-E

Datablad

Type
Cisco IOS LAN Base
Routingprotokol
Statisk IPv4 routing

Nøglefunktioner

  • Bandwidth and capacity to grow with your networking needs: 20-Gbps nonblocking switching capacity with up to 20 Gigabit Ethernet ports per switch
  • High-density industrial PoE/PoE+ support providing in-line power to up to 8 power devices, including IP cameras and phones, badge readers, wireless access points
  • Robust resiliency enabled by dual ring design via 4x Gigabit Ethernet uplink ports, Resilient Ethernet Protocol (REP), Parallel Redundancy Protocol (PRP), Etherchannel and Flexlink support, redundant power input, dying gasp
  • True zero-touch replacement for middle-of-the-night or middle-of-nowhere failure
  • Line-rate, low-latency forwarding with advanced hardware assist features (such as NAT, IEEE1588)
  • Simplified software upgrade path with universal images

Produktinformation

The Cisco Industrial Ethernet (IE) 4000 Series provides superior high-bandwidth switching and proven Cisco IOS Software-based routing capabilities for industrial environments. The IE 4000 Series delivers highly secure access and industry-leading convergence using the Cisco Resilient Ethernet Protocol (REP) and is built to withstand extreme environments while adhering to overall IT network design, compliance, and performance requirements.The IE 4000 Series is ideal for industrial Ethernet applications where hardened products are required, including factory automation, energy and process control, intelligent transportation systems (ITS), oil and gas field sites, city surveillance programs, and mining. With improved overall performance, greater bandwidth, a richer feature set, and enhanced hardware, the Cisco IE 4000 Series complements the current industrial Ethernet portfolio of related Cisco industrial switches, such as the Cisco IE 2000 and IE 3000.The Cisco IE 4000 can easily be installed in your network. Through a user-friendly web device manager, the Cisco IE 4000 provides easy out-of-the-box configuration and simplified operational manageability to deliver advanced security, data, video, and voice services over industrial networks.

Datablad

Fabrikant Cisco
Produktlinje Cisco Industrial Ethernet
Model 4000 Series
Type Switch, DIN monterbar på skinne, Cisco IOS LAN Base, 5 års garanti
Installeret størrelse 512, 0.125 MB
Autentificeringsmetode RADIUS, TACACS+
Routingprotokol Statisk IPv4 routing
Protokol til fjernadministration HTTP, SNMP 3, Telnet, CLI, SSH, RMON, RMON 2, SNMP 2, SNMP 1
Egenskaber Multicast Storm Control, Unicast Storm Control, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, NAT-understøtning, DHCP snooping, Trivial File Transfer Protocol (TFTP) support, Quality of Service (QoS), DHCP server, Dynamic ARP Inspection (DAI), Bidirectional Forwarding Detection (BFD), Uni-Directional Link Detection (UDLD), DHCP videresendelse, Port Security, MAC Address Notification, Remote Switch Port Analyzer (RSPAN), NTP tidssynkronisering, Class of Service (CoS), Precision Time Protocol (PTP), Understøttet af BOOTP, Trunking, IGMP-filtrering, VLAN-understøttet, PROFINET v2, IP-kildebekyttelse, Flex Link-support, Resilient Ethernet Protocol (REP), SmartPort-teknologi, Parallel Redundancy Protocol (PRP), IGMP snooping, Syslog understøttet, DiffServ understøttet, MAC-adresse-filtrering, Broadcast Storm Control, IPv6 understøttet
Overensstemmelsesstandarder IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1ab (LLDP), IEEE 1588v2, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 1613, IEEE 802.1s, IEEE 802.3ah, ICES-003 Klasse A, EN 61000-4-5, EN 61000-6-2, EN 61000-4-11, RoHS, EN 61000-4-8, EN 61000-6-4, IEC 60068-2-30, IEC 60068-2-27, IEC 60068-2-6, UL 508, IEC 60529 IP30, CSA 22.2 No. 142, EN 61131-2, IEC 60068-2-64, EN 61000-4-9, EN 61000-4-29, EN50155, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-52, IEC 60068-2-60, EN 50121-4, NOM-019-SCFI-1998, VCCI Class A, KN22, China RoHS, EN 50121-3-2, EN 61326, IEC 61163, CISPR 11 class A, EN 61000-4-18, IEC 61850-3, IEC/UL/CSA/EN 60950-1, IEC 60068-2-3, EN 61373, ISO 9223, CISPR 22 Klasse A, BSMI CNS 13438 Class A, CISPR 24, EN55024, EN55022 Klasse A, CB, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6
Farvekategori Sort
MTBF (forventet tid mellem fejl) 558,310 time(r)
Min. driftstemperatur -40 °C
Maks. driftstemperatur 75 °C
Fugtighedsgrad ved brug 5 - 95 % (ikke-kondenserende)
Medfølgende ledninger 1 GB SD card
Strømforbrug ved drift 35 Watt
Nominal spænding DC 9.6 - 60 V
Bredde 15.54 cm
Dybde 12.92 cm
Højde 15.54 cm
Vægt 2880 g
Hardware specification
Storage Size 0.125 GB
Usage
Software Cisco IOS LAN Base
Warranty
Warranty 5 years warranty
