Startech 4 Port PCI Express SATA III RAID Card w/ HyperDuo SSD Tiering

  • Lagerstatus: Forventet på lager: 28-02-2018
  • Forsendelse fra: 69 kr
  • Varenummer
  • 5010968503
  • Prod. varenr.


Add 4 Internal SATA III (6Gbps) ports to a computer through a PCI Express x2 slot. The PEXSAT34RH 4-Port PCI Express 2.0 SATA Controller Card with HyperDuo adds 4 AHCI SATA III ports to a computer through a PCIe slot (x2), delivering multiple internal 6Gbps connections for high-performance hard drives and Solid State Drives (SSDs).
Featuring HyperDuo technology, the SATA card offers SSD auto-tiering which lets you balance the performance advantages of SSD storage with the cost-effectiveness and large capacity of standard hard drives. By combining SSD and HDD drives into a single volume (up to 3 SSD + 1 HDD), HyperDuo discreetly works in the background to identify and move frequently accessed files to the faster SSD drive(s) for improved data throughput - up to 80% of SSD performance! (Note: The HyperDuo automatic storage tiering feature is compatible with computers that use a BIOS.)
The PCIe SATA controller card supports Port Multiplier (PM), enabling multiple SATA drives to be connected to one port over a single cable, for a total of 7 drives (Up to 4 drives through PM on one port, and a single drive to the remaining 3 ports). Plus, the SATA controller card offers an effective hardware RAID solution, with native RAID (0, 1, 1+0) support.


Antal pakker 1
Model 4 Port PCI Express SATA III RAID Card w/ HyperDuo SSD Tiering
Ekspansion / Konnektivitet
Tilslutninger 4 x SATA 6Gb/s - 7 pin Serial ATA ( internal )
Enhedstype Storage controller (RAID) - plug-in card - low profile
Produkttype Styreenhed til lagring (RAID)
Controller for lagring
Interface PCIe 2.0 x2
Grænseflade SATA 6Gb/s
Antal kanaler 4
Formfaktor Indstikskort
RAID-niveau JBOD, RAID 10, RAID 1, RAID 0
Understøttede enheder Diskarray (RAID)
Storage Controller
Data Transfer Rate 6 GBps
Included accessories
Included Accessories Low-profile bracket
Understøttet OS Windows 10 (32/64 bits), Apple MacOS X 10.8, Windows 8 (32/64 bit), Apple MacOS X 10.7 Lion, Microsoft Windows XP (32/64 bits), Microsoft Windows 7 (32/64 bits), Microsoft Windows Vista (32/64 bits), Apple MacOS X 10.6, Linux
Kompatible standarder
Kompatible standarder FCC, RoHS
Min. driftstemperatur 5 °C
Maks. driftstemperatur 50 °C
Luftfugtighed ved drift 20 - 80% (non-condensing)
Mål og vægt
Ydermål bredde 12 cm
Ydermål dybde 7 cm
Ydermål højde 2 cm
Vægt 0.05 kg
Service & Support
Service og Support 2 års garanti
Service & Support Details Limited warranty - 2 years

Anmeldelser af Startech 4 Port PCI Express SATA III RAID Card w/ HyperDuo SSD Tiering

(1 bedømmelser)

Perfekt produkt

Ganske udemærket produkt, og top ydelse på ssd i single og raid.

Från: Peter Jensen - 2016-09-01 13:03:08
